Aluminum Lifting Beam · ASME B30.20 / BTH-1 Category B

Built Light.
Matched to Your Crane.

Capacity
1,000 – 10,000 LB
Spread Range
2 – 28 FT
Designed To
B30.20 / BTH-1 CAT B
Starting At
$1,323 USD

Aluminum lifting beams from 1,000 to 10,000 lb capacity. Two product lines — Compact (3×6) up to 6,000 lb and High Capacity (3×12) up to 10,000 lb — each matched to a class of portable cranes. Up to 84% lighter than steel at equivalent capacity. ASME B30.20 and ASME BTH-1 Category B compliant with a 3:1 design factor.

Get a Quote→ Download Spec Sheet→
Eagle Beam
Eagle Beam · all-aluminum, all-bolted lifting beam
Engineered, Welded, and Tested for North American Jobsites
Engineered to
  • ASME BTH-1 Category B Design of Below-the-Hook Lifting Devices
  • ASME B30.20 Below-the-Hook Lifting Devices — safety
  • Aluminum Design Manual (ADM) US aluminum structural design
  • CSA S157 Strength Design in Aluminum
Construction
All-Bolted Construction
No welded joints in the load-bearing structure — so welding certification does not apply. The HAZ failure mode in welded aluminum is eliminated by design.
Weight on the Job

See what your crane isn't carrying.

Real weight comparisons at popular capacity and spread combinations. The red bar is Eagle Beam. The gray bar is what your crane has been lifting.

1,000 lb 25 ft Spread
Steel
1,340 lb
Eagle Beam
313 lb
−1,027 lb saved
2,000 lb 21 ft Spread
Steel
1,095 lb
Eagle Beam
273 lb
−822 lb saved
4,000 lb 21 ft Spread
Steel
1,730 lb
Eagle Beam
273 lb
−1,457 lb saved
10,000 lb 10 ft Spread
Steel
390 lb
Eagle Beam
132 lb
−258 lb saved
44 lb
Lightest beam configuration
1,457 lb
Maximum weight saved vs. steel
84%
Lighter than steel at equivalent capacity

Steel comparison based on published / catalog steel lifting-beam weights for equivalent rated capacity and spread. Exact steel beam weight varies by manufacturer, service class, and configuration.

Technical Spec Matrix

Capacity & weight by spread.

Estimated beam weight (lb) at each spread position, by capacity. Adjustable spread positions: 3 per side on beams 6 ft and greater, 4 per side on beams over 20 ft. Custom spreads and lengths available on request.

Beam weight (lb) by capacity and spread
Capacity2–3′3–4′4–6′6–8′8–10′10–12′12–14′14–16′16–18′18–20′21–24′25–28′
10,000 lb617191111132———————
6,000 lb445061111132152172192212———
4,000 lb4450617284152172192212233273—
2,000 lb445061728495172192212233273313
1,000 lb445061728495106118129140273313
All capacities ASME B30.20 / BTH-1 compliant with a 3:1 design factor. Rated for symmetrical lifts only. Dashes indicate spreads not offered at that capacity.
What Makes It Different

Four design choices that set Eagle Beam apart.

eme makes one below-the-hook lifting device — and it's built for the parts of the job that don't tolerate guesswork. Every feature below was chosen to remove a category of risk from your lift.

Construction

All-bolted. Zero welds in the load path.

Every load-bearing joint on Eagle Beam uses a Grade L9 fastener, not a weld. No heat-affected zones, no weld-quality risk to certify, no consumable-related variation between units. The beam ships exactly as designed — the bolts are the design.

About Grade L9 fasteners→
Weight

Up to 84% lighter than steel.

At equivalent capacity, an Eagle Beam weighs a fraction of its steel counterpart. The lightest configuration is 44 lb — one-sixth the weight of the equivalent steel beam. Crews carry, position, and adjust by hand; no second crane to move the lifting beam.

Aluminum vs. steel guide→
Standard

ASME BTH-1 Category B. 3:1 design factor.

Eagle Beam is designed to the conservative end of the BTH-1 framework — appropriate to portable, multi-jobsite, variable-operator service. Three times the rated load handled at yield stress, with documented margin beyond.

What is ASME BTH-1?→
Verification

Load-tested to 125% before shipment.

Every unit is load-tested to 125% of rated capacity using a calibrated load cell. The Certificate of Test — with the date, capacity, and verified result — ships with the beam. Critical for ports, utilities, nuclear, and any regulated worksite.

How load testing works→
The Eagle Beam Lineup

Two product lines. Matched to your crane.

eme makes Eagle Beam in two distinct product lines, each built for a class of portable crane. Pick the line that matches your equipment — capacity, spread, and beam profile are sized to the cranes the line is engineered to pair with.

3×6

Eagle Beam · Compact

1,000 – 6,000 lb up to 20 ft

For portable cranes in the 1,000–6,000 lb class. Compact profile, lighter beam at every spread.

Starting at $1,323 USD

Model EB2000-36-45 · 2,000 lb · 2–3 ft spread

Pairs with
  • eme gantries — 1100R, 2200R, 4400R, 6600R
  • eme davit cranes
  • Service truck cranes
  • Spider cranes (small)
  • Small jib cranes
3×12

Eagle Beam · High Capacity

1,000 – 10,000 lb up to 28 ft

For portable cranes in the 6,000–10,000 lb class. Deeper section for higher capacity and longer spreads.

Starting at $3,014 USD

Model EB2000-312-177 · 2,000 lb · 12–14 ft spread

Pairs with
  • eme gantries — 11000R, 22000R
  • Mid-capacity spider cranes
  • Larger service truck cranes
  • Similar portable cranes in the 6,000–10,000 lb class
Engineered For eme gantries · eme davit cranes · service truck cranes · portable gantries · mobile lifting frames · spider cranes · small jib cranes · monorails — rated to 10,000 lb.
Not For Crawler cranes · tower cranes · shipyard derricks — use steel spreaders rated to that equipment.
Standards & Documentation

The only third-party-certifiable claim is the one that doesn't apply.

The structural welds on most eme gantries and davits are produced by a company certified by CWB to CSA W47.2 — the Canadian Welding Bureau credential for fusion welding of aluminum. Eagle Beam doesn't carry W47.2 because it has no welded joints in the load-bearing structure. That's the design, not an omission.

  • Built around ASME B30.20. The American Society of Mechanical Engineers standard for below-the-hook lifting devices. Governs marking, inspection, testing, and operation. Eagle Beam attaches between the crane's load hook and the load — the crane itself (a gantry or davit) is separate lifting equipment with its own crane standards; the Eagle Beam operates under B30.20 as the below-the-hook device.
  • Designed to ASME BTH-1 Category B with a 3:1 design factor on yield stress. The conservative end of the BTH-1 framework — appropriate to portable, variable-operator, multi-jobsite service.
  • All-bolted construction with SAE J429 Grade 9 (Grade L9) fasteners — 180 ksi minimum tensile strength, 145 ksi proof load. No welded joints in the load-bearing structure — by design, not by accident. CSA W47.2 doesn't apply because there are no production welds to certify.
  • 6061-T6 aluminum structural members. The standard alloy for portable aluminum lifting equipment. Aluminum Design Manual (ADM) design minimums are Fty = 35 ksi and Ftu = 38 ksi (typical mill-certified properties run higher — yield ~40 ksi, tensile ~45 ksi).
  • Load-tested to 125% of rated capacity with a calibrated load cell. Certificate of Test ships with every beam — capacity, test load, method, and date documented for any regulated worksite that requires it.
See Standards Reference→

Configure your Eagle Beam.

Tell us your lift — capacity, spread, lifting points, jobsite — and we'll spec the right Eagle Beam configuration. Quote and lead-time within one business day.

Request a Quote→ Find a Rental→
